Specifications
| Nominal capacity | 40L |
| Shell thickness | 4mm |
| Cylinder heights | 1040mm |
| Nominal diameter | 250mm |
| Hydraulic test pressure | 5.2MPa |
| Sealing test pressure | 3.0MPa |
| Limited filling pressure (15℃) | 1.56MPa |
| Porous mass property parameters | |
| Compressive strength | ≥1.8MPa |
| Porosity | 90-92% |
| The axial space at the cylinder shoulder | ≤2.5mm |
| Solvant | Acetone（13.6kg） |
| Acetylene weight | 6.8kg |
| Maximum working temperature | ≤40℃ |
| Packing | Nude packing |
| Loading | 500pcs for 1x20 feet container |
